- Easy to read silkscreened scale
- Dual scale measuring in both GPM and LPM
- Injection molded for liquid
- Low pressure drop
- Easy to assemble
- Control valve available
- Simple and robust design with high operational safety
| Model | Measuring Range | Thread (M/BSP) | |
| GPM | LPM | ||
| Z-300KT 1 | 0.1 – 1 | 0.5 – 4 | 1/2″ |
| Z-300KT 2 | 0.2 – 2 | 1 – 7 | |
| Z-300KT 3 | 0.5 – 5 | 2 – 18 | |
| Z-300KT 4 | 1 – 10 | 5 – 35 | 3/4″ |
| Z-300KT 5 | 2 – 14 | 10 – 50 | |
| Z-300KT 6 | 2 – 20 | 12 – 70 | 1″ |
| Z-300KT 7 | 5 – 35 | 10 – 130 | |
DIMENSIONS
| Model | A | B | C | D | E | F | G | H |
| KT1 / KT2 / KT3 | 168 | 30 | 34 | 176 | 25 | 25 | 127 | 76 |
| KT4 / KT5 / KT6 / KT7 | 226 | 45 | 46 | 232 | 48 | 33 | 165 | 100 |
The Flowtech panel flowmeters feature a rugged, one-piece acrylic body, stainless steel internal parts, rear inlet and outlet plastic ports for panel mounting. The stainless steel float guide helps reduce float oscillation and improve overall performance. The tapered bore is precision machined to a smooth surface that provides perfect visibility of the indicating float. For greater versatility and control, the panel flow meters may be ordered with an integral flow adjustment valve.
Silk screened printing dual scale measuring in both GPM and LPM flow range, with accuracy ±6%, maximum temperature 55˚C and maximum pressure 6 bar.
